Description
Knox Argon VM II 6000 5KW Off-Grid Solar Inverter with PV 6000W
The Knox Argon VM II 6000 is a reliable off-grid solar inverter designed for efficient power management in off-grid solar systems. With its IP21-rated design, it is ideal for indoor installations, offering easy monitoring and installation.
Key Features
- IP21-rated Design for Indoor Use: Ensures reliable performance in protected indoor environments, safeguarding the inverter from dust and water splashes.
- 6000W PV Input: Supports bifacial solar panel output, maximizing energy generation and efficiency from the solar array.
- Wide MPPT Voltage Range (120 – 450V): Offers flexibility in solar panel selection and ensures optimal power conversion for various configurations.
- Quick & Easy Installation: Designed for easy setup with standard tools, making the installation process straightforward.
- Easy Commissioning & Monitoring: Features an LED screen on the inverter for live monitoring, allowing easy access to system performance and settings.
The Knox Argon VM II 6000 is a great choice for off-grid solar systems, offering durability, flexibility, and efficient power conversion with user-friendly features.
Technical Data Sheet:
| Rated Power | 5000VA/5000W |
| INPUT | |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Surge Power | 10000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| BATTERY | |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 63 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Array Power | 6000W |
| MPP Range @ Operating Voltage | 120 ~ 450VDC |
| Maximum Solar Charge Current | 100A |
| Maximum AC Charge Current | 100A |
| Maximum Charge Current | 100A |
| PHYSICAL | |
| Dimension, D x W x H (mm) | 120 x 300 x 440 |
| Net Weight (kgs) | 10 |
| Communication Interface | RS232/RS485, optional WiFi |
| ENVIRONMENT | ENVIRONMENT |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
